BECHEM Forge 840for top performance in massive forming

Scroll
The new lubricant for outstanding product quality

The aqueous dispersion BECHEM Forge 840 has been specially designed for highly automated processes in the areas of hot, warm and precision forging and sets new standards in terms of sustainability and efficiency.



BECHEM Forge 840 is low-odour and low-smoke and is characterized by its unique fine particle size, which achieves outstanding product quality, especially for the requirements of highly complex formed parts. Thanks to a special stabilization system, the aqueous dispersion not only ensures improved processing, but also increased reliability in the forging process. This makes a decisive contribution to reducing rejects and improving overall quality.



The new formulation selection improves release behaviour and minimizes tool wear. Users benefit from longer tool life and more sustainable use of resources. In order to achieve an optimum coating thickness on the forging die, BECHEM recommends application in diluted form using spraying equipment.



BECHEM Forge 840 is the ideal solution for die forgers who want to make their production process more sustainable and who are looking for top performance in forging technology.

Advantages of the BECHEM Forge 840

very fine particle size
under 1 μm
Evaporation residue at 135 °C
25 %
Dyn. viscosity at 23 °C
1000-1200
pH value
10.0-11.5
Properties
  • After spraying and drying, a black layer of active ingredient remains on the tool, which provides a good release and lubricating effect during the forming process
  • Good release properties
  • Good pumpability
  • Wear protection
  • Lubricant containing solids with very fine particle size
  • Ammonia-free
  • PFAS-free
Applications
  • Apply to the tool using a suitable spraying system, whereby fine atomization is advantageous
  • For extreme applications with tool temperatures up to 350 °C and in loss lubrication up to 1,280 °C
  • Cooling and lubrication
Materials to be processed
  • Non-ferrous metals
  • Stainless steel
  • Steel

Find the right lubricant nowWith the BECHEM Product Finder

Marc Chwalek

Global Technology/Market Manager Forging


Send me an e-mail

BECHEM expert for:

- massive forming

- Semi-hot and hot forming



Contact
